Starter Motor Models 133, 135, 140, 145, 148, 152, 155, 158, 165, 230, 235, 240, 245, 250, 253, 254, 255, 35 3-Cylinder, 350, 352, 355, 360, 550, 65
Product Details
Product Details
Kilowatts – 2.2KW
Number of Teeth – 10
Number of mounting holes - 3
Mounting holes Distance – 146mm
Mounting Angle – 45 degrees
Clockwise rotation
For flywheel depth – 28.7mm
52701 is a direct replacement for the original Lucas M45 starter
motor. Commonly fitted to a large range of Massey Ferguson tractors where the
starter motor is mounted on the right-hand side of the engine. Manufactured
using high grade copper for the internals this ensures the starter will last
and be efficient. All external joints are sealed to keep out any moisture.
When fitted to Massey Ferguson 165 tractors it is only
compatible when fitted with the Perkins A4.203 Engine
Its not uncommon for a starter to fail after years of
service, usual signs the starter motor is on its way out would be a single
click from the starter or a series of rapid clicks when the ignition switch is
turned to the start position, these symptoms can also point to a faulty
solenoid rather than the motor itself. Due to the value for money on a completely
new starter it makes sense to change the unit rather than just the solenoid.
The solenoid has spade and bolt on terminals ready to connect
the wiring up, its important to check that all the wires are making a good
connection to both starter motor and tractor otherwise this could lead to
further starting issues.
