Starter Motor Ferguson TEF Models 20C, FF30, TEF20
Product Details
Product Details
Kilowatts – 2.2KW
Number of Teeth – 11
Number of mounting holes – 3
Mounting hole diameter – 11mm
Total Length – 380mm
50097A is a direct replacement for the original Lucas 26071F
starter motor. Commonly fitted to Ferguson TEF tractors, mounted on the Left-hand
side of the engine. Known as a pre engage starter fitted with an adjustable
mounted contact switch and rubber boot. Manufactured using high grade copper
for the internals this ensures the starter will last and be efficient. All
external joints are sealed to keep out any moisture.
The starter has been developed to fit straight onto a TEF Ferguson, you will find other suppliers selling the same starter for the Fordson
and Ferguson tractors, however these wont fit directly onto a TEF with out
bending some components into shape as the contact switch is at a slightly
different Angle. You wont have any of these issues with 50097A
Starter motor
cranking is activated by depressing a manual lever which contacts a switch
sending power from the battery to the coil of a remote solenoid. Energising the
solenoid coil causes the solenoid main contacts to close allowing flow of high
current circuit from the battery to the starter motor. It’s
not uncommon for a starter to fail after years of service especially with these
starters as the rubber boot is prone to perishing allowing moisture in. Usual
signs the starter motor is on its way out would be a single click from the
starter or a series of rapid clicks when the ignition switch is turned to the
start position, these symptoms can also point to a faulty solenoid rather than
the motor itself.
If you require the rubber boot this is Agriline part number
5191
For original starter motors the contact switch is Agriline
part number 5063
The Contact switch has 2 screw threaded terminals ready to
connect the wiring up, its also important to check that the contact switch is
set right so that the push lever makes contact with the switch and all the
wires are making a good connection to both starter motor and tractor otherwise
this could lead to further starting issues.
